Product Details
- Size: 5
- Place of Origin: China
- Brand Name: WEITUO
- Model Number: LZ25-45
- Weight: 1400.000 kg
Tractor Advantages:
1) 3/4-cylinder engine;
2) Power steering;
3) Multi-valve hydraulic output;
4) PTO Rev. 540/1000 rpm;
5) Wheel tread adjusted steplessly;
6)Shuttle gear optional
- Size: 5
- Place of Origin: China
- Brand Name: WEITUO
- Model Number: LZ25-45
- Weight: 1400.000 kg
| Model | Luzhong254 | Luzhong264 | Luzhong304 | Luzhong354 | Luzhong404 | Luzhong454 | ||
| Type | 4×4 Wheeled Type | 4×4 Wheeled Type | 4×4 Wheeled Type | 4×4 Wheeled Type | 4×4 Wheeled Type | 4×4 Wheeled Type | ||
| Dimensions of Tractor （mm） | Length | 3250 | 3250 | 3250 | 3455 | 3700 | 3700 | |
| Width | 1450 | 1450 | 1450 | 1515 | 1615 | 1615 | ||
| Height | 2030 | 2030 | 2030 | 2040 | 2130 | 2130 | ||
| Tread | Front Wheel | 960、1220(ususl) | 960、1220(ususl) | 960、1220(ususl) | 960、1220(ususl) | 1250 | 1250 | |
| Rear Wheel | 960、1160（usual）、1200、1300 | 960、1160（usual）、1200、1300 | 960、1160（usual）、1200、1300 | 960、1160、1200（usual）、1300 | 1200、1300（usual）、1400 | 1200、1300（usual）、1400 | ||
| Wheel Base | 1715 | 1715 | 1715 | 1835 | 2010 | 2010 | ||
| Min. Ground Base | 300（the bottom of transfer case） | 300（the bottom of transfer case） | 300（the bottom of transfer case） | 320(the bottom of front axle) | 325（the bottom of steering horizontal pulling rod） | 325（the bottom of steering horizontal pulling rod） | ||
| Min. Usage Mass（kg） | 1440 | 1440 | 1440 | 1700 | 2160 | 2160 | ||
| Engine | Model | Laidong KM385 | Laidong KM385BT | Laidong KM390BT | Laidong 4L22BT | Changchai ZN490BT | Xinchang A495BT | |
| Type | Vertical, water cooled and 4-stroke | Vertical, water cooled and 4-stroke | Vertical, water cooled and 4-stroke | Vertical, water cooled and 4-stroke | Vertical, water cooled and 4-stroke | Vertical, water cooled and 4-stroke | ||
| Rated Power （kw） | 18.4 | 19.1 | 22.1 | 25.7 | 29.4 | 33.1 | ||
| Rated Rev.（r/min） | 2300 | 2400 | 2300 | 2350 | 2300 | 2400 | ||
| Fuel | Diesel Oil | Diesel Oil | Diesel Oil | Diesel Oil | Diesel Oil | Diesel Oil | ||
| Tire | Front Wheel | 6.00-16 | 6.00-16 | 6.00-16 | 6.50-16 | 8.3-20 | 8.3-20 | |
| Rear Wheel | 9.50-24 | 9.50-24 | 9.50-24 | 11.2-24 | 12.4-28 | 12.4-28 | ||
| Clutch | Dry-friction, single disc, two stage and constant engagement | Dry-friction, single disc, two stage and constant engagement | Dry-friction, single disc, two stage and constant engagement | Dry-friction, single disc, two stage and constant engagement | dry-friction, single disc and two stage | dry-friction, single disc and two stage | ||
| Steering | Hydraulic type | Hydraulic type | Hydraulic type | Hydraulic type | Hydraulic type | Hydraulic type | ||
| Transmission Box | （4 1）×2 Composed | （4 1）×2 Composed | （4 1）×2 Composed | （4 1）×2 Composed | two shafts, 4×（2 1） composed | two shafts, 4×（2 1） composed | ||
| Suspension Type | Post Positioned Tri-point Suspension Catalogue Ⅰ | Post Positioned Tri-point Suspension Catalogue Ⅰ | Post Positioned Tri-point Suspension Catalogue Ⅰ | Post Positioned Tri-point Suspension Catalogue Ⅰ | Post Positioned Tri-point Suspension Catalogue Ⅰ | Post Positioned Tri-point Suspension Catalogue Ⅰ | ||
| PTO | Type and Rev. （r/min） | Post-position, half-independent, 540/760 | Post-position, half-independent, 540/760 | Post-position, half-independent, 540/760 | Post-position, half-independent, 540/760 | Post-position, half-independent, 540/760 | Post-position, half-independent, 540/760 | |
| Spline Size | I35 Rectangle Spline with 6 teeth | I35 Rectangle Spline with 6 teeth | I35 Rectangle Spline with 6 teeth | I35 Rectangle Spline with 6 teeth | I35 Rectangle Spline with 6 teeth | I35 Rectangle Spline with 6 teeth | ||
